CMR03C1R5DOCM
RoHS
/
Package Radial
Category Capacitors / Mica and PTFE Capacitors
Description
CMR Radial Mica Capacitor 0.272Lx0.110W 6.90mmx2.80mm -200/+200ppm/Cel ppm/C ±0.5pF 1.5pF
PDF
/
Inventory: 7114
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Through Hole
Package / Case Radial
Surface Mount NO
Terminal Shape WIRE
Dielectric Material Mica
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series CMR
Size / Dimension 0.272Lx0.110W 6.90mmx2.80mm
Tolerance ±0.5pF
JESD-609 Code e0
Feature General Purpose
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Temperature Coefficient -200/+200ppm/Cel ppm/°C
Terminal Finish Tin/Lead (Sn60Pb40)
Voltage - Rated 300V
HTS Code 8532.29.00.20
Capacitance 1.5pF
Terminal Pitch 3mm
Reference Standard MIL-PRF-39001
Lead Spacing 0.118 3.00mm
Rated (DC) Voltage (URdc) 300V
Size Code 2711
Dimensions
Height Seated (Max) 0.189 4.80mm
Length 6.9mm
Width 2.8mm
Compliance
RoHS Status Non-RoHS Compliant
