CD5EC200DO3F
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Capacitors / Mica and PTFE Capacitors
Description
CD5 Radial Mica Capacitor 0.272Lx0.118W 6.90mmx3.00mm 100ppm/C ±0.5pF 20pF
PDF
/
Buying Options
Total Price: USD $10.62
Unit Price: USD $10.624364
≥1 USD $10.624364
≥10 USD $10.022982
≥100 USD $9.455644
≥500 USD $8.920418
≥1000 USD $8.415491
Inventory: 2297
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 6.9mm
Height Seated (Max) 0.201 5.10mm
Height 5.1mm
Technical
Size Code 2712
Lead Spacing 0.118 3.00mm
Lead Pitch 2.9972mm
Terminal Pitch 3mm
Packing Method TR
Voltage - Rated DC 300V
Capacitance 20pF
HTS Code 8532.29.00.20
Terminal Finish Tin (Sn)
Temperature Coefficient 100 ppm/°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature General Purpose
JESD-609 Code e3
Tolerance ±0.5pF
Size / Dimension 0.272Lx0.118W 6.90mmx3.00mm
Series CD5
Published 2013
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Dielectric Material Mica
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 14 Weeks
