CD17ED220JO3F
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Capacitors / Mica and PTFE Capacitors
Description
CD17 Radial Mica Capacitor 0.449Lx0.169W 11.40mmx4.30mm -20/+100ppm/Cel ppm/C ±5% 22pF
PDF
/
Buying Options
Total Price: USD $4.06
Unit Price: USD $4.059487
≥1 USD $4.059487
≥200 USD $1.620119
≥500 USD $1.56629
≥1000 USD $1.538719
Inventory: 4227
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Terminal Shape WIRE
Dielectric Material Mica
Technical
Operating Temperature -55°C~150°C
Packaging Bulk
Published 2009
Series CD17
Size / Dimension 0.449Lx0.169W 11.40mmx4.30mm
Tolerance ±5%
JESD-609 Code e3
Feature RF, High Q, Low Loss
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Temperature Coefficient -20/+100ppm/Cel ppm/°C
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
HTS Code 8532.29.00.20
Capacitance 22pF
Voltage - Rated DC 500V
Packing Method TR
Terminal Pitch 5.9mm
Lead Pitch 5.8928mm
Lead Spacing 0.232 5.90mm
Size Code 4517
Dissipation Factor 0.05 %
Dimensions
Height Seated (Max) 0.358 9.10mm
Length 11.4mm
Width 4.3mm
Compliance
RoHS Status ROHS3 Compliant
