W25Q64JVSSIQ
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Memory
Description
3A991.B.1.A Surface Mount Tube 64MX1 ic memory 133MHz 6ns 2.16mm 512Mb
PDF
/
Buying Options
Total Price: USD $1.29
Unit Price: USD $1.28884
≥1 USD $1.28884
≥10 USD $1.21588
≥100 USD $1.14706
Inventory: 5824
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.209, 5.30mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2016
Series SpiFlash?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
ECCN Code 3A991.B.1.A
Terminal Finish Matte Tin (Sn) - annealed
Technology FLASH - NOR
Voltage - Supply 2.7V~3.6V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 30
Operating Supply Voltage 3V
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2.7V
Interface SPI
Memory Size 64Mb 8M x 8
Memory Type Non-Volatile
Operating Mode SYNCHRONOUS
Clock Frequency 133MHz
Access Time 6 ns
Memory Format FLASH
Memory Interface SPI - Quad I/O
Organization 64MX1
Memory Width 1
Write Cycle Time - Word, Page 3ms
Address Bus Width 24b
Density 512 Mb
Parallel/Serial SERIAL
Programming Voltage 2.7V
Page Size 256B
Ambient Temperature Range High 85°C
Dimensions
Height 2.16mm
Length 5.23mm
Compliance
RoHS Status ROHS3 Compliant
