BQ2022DBZRG4
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / Memory
Description
Obsolete OPEN-DRAIN Serial DUAL EPROM Memory -40C~85C TA 2.65V 1kb 0.00002mA
PDF
/
Buying Options
Total Price: USD $0.48
Unit Price: USD $0.48355
≥1 USD $0.48355
≥10 USD $0.39615
≥100 USD $0.3838
≥500 USD $0.37145
≥1000 USD $0.3591
Inventory: 1505
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Surface Mount YES
Number of Pins 3
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory OTP ROMs
Technology EPROM - OTP
Voltage - Supply 2.65V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.7V
Terminal Pitch 0.95mm
Base Part Number BQ2022
Pin Count 3
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.65V
Interface Serial
Memory Size 1Kb 256b x 4 pages
Memory Type Non-Volatile
Clock Frequency 0.01667MHz
Supply Current-Max 0.00002mA
Memory Format EPROM
Memory Interface Single Wire
Organization 1KX1
Output Characteristics OPEN-DRAIN
Memory Width 1
Density 1 kb
I/O Type COMMON
Dimensions
Height Seated (Max) 1.12mm
Length 2.92mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
