M95M01-RMW6G
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount M95M01 Tube ic memory 16MHz 80ns 5.62mm 5mA
PDF
/
Buying Options
Total Price: USD $7.95
Unit Price: USD $7.948297
≥1 USD $7.948297
≥180 USD $3.171966
≥540 USD $3.065622
≥990 USD $3.013106
Inventory: 6126
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.209, 5.30mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Technology CMOS
Voltage - Supply 1.8V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.5V
Terminal Pitch 1.27mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number M95M01
Pin Count 8
Qualification Status Not Qualified
Operating Supply Voltage 5V
Interface SPI, Serial
Memory Size 1Mb 128K x 8
Nominal Supply Current 5mA
Memory Type Non-Volatile
Operating Mode SYNCHRONOUS
Clock Frequency 16MHz
Access Time 80 ns
Memory Format EEPROM
Memory Interface SPI
Memory Width 8
Write Cycle Time - Word, Page 5ms
Density 1 Mb
Standby Current-Max 0.000003A
Serial Bus Type SPI
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 5ms
Data Retention Time-Min 40
Write Protection HARDWARE/SOFTWARE
Dimensions
Height Seated (Max) 2.5mm
Width 5.62mm
Compliance
RoHS Status ROHS3 Compliant
