M95320-WMN6TP
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount M95320 Tape & Reel (TR) ic memory 20MHz 40ns 3.9mm 5mA
PDF
/
Buying Options
Total Price: USD $0.36
Unit Price: USD $0.3608
≥1 USD $0.3608
≥10 USD $0.35728
≥100 USD $0.331936
≥500 USD $0.330176
≥1000 USD $0.293304
≥3000 USD $0.289555
Inventory: 9821
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold/Silver (Ni/Pd/Au/Ag)
Additional Feature 1 MILLION ERASE/WRITE CYCLES; 40 YEARS DATA RETENTION
Technology CMOS
Voltage - Supply 2.5V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number M95320
Pin Count 8
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3/5V
Supply Voltage-Min (Vsup) 2.5V
Interface SPI, Serial
Memory Size 32Kb 4K x 8
Nominal Supply Current 5mA
Memory Type Non-Volatile
Clock Frequency 20MHz
Access Time 40 ns
Memory Format EEPROM
Memory Interface SPI
Write Cycle Time - Word, Page 5ms
Density 32 kb
Standby Current-Max 0.000002A
Programming Voltage 2.7V
Serial Bus Type SPI
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 5 ms
Data Retention Time-Min 40
Write Protection HARDWARE/SOFTWARE
Dimensions
Height 1.25mm
Length 4.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
