M95010-RMN6TP
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount M95010 Tape & Reel (TR) ic memory 20MHz 60ns 3.9mm 5mA
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.40147
≥1 USD $0.40147
≥10 USD $0.37874
≥100 USD $0.3573
≥500 USD $0.33708
≥1000 USD $0.318
≥3000 USD $0.3
Inventory: 9800
Minimum: 1
-
+
Technical Details
Technical
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology CMOS
Voltage - Supply 1.8V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number M95010
Pin Count 8
Operating Supply Voltage 5V
Interface SPI, Serial
Memory Size 1Kb 128 x 8
Nominal Supply Current 5mA
Memory Type Non-Volatile
Clock Frequency 20MHz
Access Time 60 ns
Memory Format EEPROM
Memory Interface SPI
Memory Width 8
Write Cycle Time - Word, Page 5ms
Density 1 kb
Standby Current-Max 0.0005A
Serial Bus Type SPI
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 5ms
Data Retention Time-Min 40
Write Protection HARDWARE/SOFTWARE
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Width 3.9mm
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 13 Weeks
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
