M93C66-MN6TP
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount M93C66 Tape & Reel (TR) ic memory 2MHz 200ns 3.9mm 0.00005A
PDF
/
Buying Options
Total Price: USD $5.29
Unit Price: USD $5.28675
≥1 USD $5.28675
≥10 USD $4.3377
≥100 USD $4.20185
≥500 USD $4.06695
≥1000 USD $3.9311
Inventory: 5159
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8542.32.00.51
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number M93C66
Pin Count 8
JESD-30 Code R-PDSO-G8
Operating Supply Voltage 5V
Power Supplies 5V
Interface Serial
Memory Size 4Kb 512 x 8 256 x 16
Memory Type Non-Volatile
Clock Frequency 2MHz
Supply Current-Max 0.002mA
Access Time 200 ns
Memory Format EEPROM
Memory Interface SPI
Organization 256X16
Memory Width 16
Write Cycle Time - Word, Page 5ms
Density 4 kb
Standby Current-Max 0.00005A
Serial Bus Type MICROWIRE
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 5ms
Data Retention Time-Min 40
Write Protection SOFTWARE
Alternate Memory Width 8
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
