M93C46-WMN6P
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
e4 Surface Mount M93C46 Tube ic memory 2MHz 200ns 3.9mm 2mA
PDF
/
Buying Options
Total Price: USD $0.19
Unit Price: USD $0.1936
≥1 USD $0.1936
≥10 USD $0.19184
≥100 USD $0.178464
≥500 USD $0.177408
≥1000 USD $0.15752
≥3000 USD $0.155496
Inventory: 10988
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Manufacturer Package Identifier SO8N-SO-A
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Technology CMOS
Voltage - Supply 2.5V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number M93C46
Pin Count 8
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3/5V
Supply Voltage-Min (Vsup) 2.5V
Memory Size 1Kb 128 x 8 64 x 16
Nominal Supply Current 2mA
Memory Type Non-Volatile
Clock Frequency 2MHz
Access Time 200 ns
Memory Format EEPROM
Memory Interface SPI
Organization 64X16
Write Cycle Time - Word, Page 5ms
Density 1 kb
Standby Current-Max 0.00001A
Parallel/Serial SERIAL
Serial Bus Type MICROWIRE
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 5 ms
Data Retention Time-Min 40
Write Protection SOFTWARE
Ambient Temperature Range High 85°C
Dimensions
Height 1.75mm
Length 4.9mm
Width 3.9mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
