M48Z58-70PC1
RoHS
RoHS compliant
RoHS compliantPackage 28-DIP Module (0.600, 15.24mm)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Through Hole M48Z58 Tube ic memory 1MHz 70ns 18.34mm 50mA
PDF
/
Buying Options
Total Price: USD $17.61
Unit Price: USD $17.6088
≥1 USD $17.6088
≥10 USD $16.40027
≥100 USD $16.224754
≥500 USD $15.8246
≥1000 USD $13.891698
≥3000 USD $13.423071
Inventory: 262
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 25 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 28-DIP Module (0.600, 15.24mm)
Number of Pins 28
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Terminal Finish Tin (Sn)
Additional Feature BATTERY BACK-UP; POWER SUPPLY WRITE PROTECTION
HTS Code 8542.32.00.41
Subcategory SRAMs
Technology NVSRAM (Non-Volatile SRAM)
Voltage - Supply 4.75V~5.5V
Terminal Position DUAL
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 2.54mm
Frequency 1MHz
Base Part Number M48Z58
Pin Count 28
Operating Supply Voltage 5V
Power Supplies 5V
Memory Size 64Kb 8K x 8
Operating Supply Current 50mA
Number of Ports 1
Nominal Supply Current 50mA
Memory Type Non-Volatile
Memory Format NVSRAM
Memory Interface Parallel
Data Bus Width 8b
Organization 8KX8
Output Characteristics 3-STATE
Write Cycle Time - Word, Page 70ns
Address Bus Width 13b
Density 64 kb
Standby Current-Max 0.003A
Access Time (Max) 70 ns
Word Size 8b
Output Enable YES
Dimensions
Height 8.89mm
Length 39.88mm
Width 18.34mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
