M29F010B45K1
RoHS
RoHS compliant
RoHS compliantPackage 32-LCC (J-Lead)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount M29F010 Tube ic memory 45ns 13.97mm 0.0001A 8b
PDF
/
Buying Options
Total Price: USD $4.88
Unit Price: USD $4.88205
≥1 USD $4.88205
≥10 USD $4.0052
≥100 USD $3.88075
≥500 USD $3.75535
≥1000 USD $3.62995
Inventory: 7002
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 13.97mm
Height Seated (Max) 3.56mm
Technical
Sector Size 16K
Number of Sectors/Size 8
Command User Interface YES
Toggle Bit YES
Data Polling YES
Endurance 100000 Write/Erase Cycles
Programming Voltage 5V
Access Time (Max) 45 ns
Memory Density 1048576 bit
Standby Current-Max 0.0001A
Write Cycle Time - Word, Page 45ns
Memory Width 8
Organization 128KX8
Data Bus Width 8b
Memory Interface Parallel
Memory Format FLASH
Supply Current-Max 0.02mA
Operating Mode ASYNCHRONOUS
Memory Type Non-Volatile
Memory Size 1Mb 128K x 8
Supply Voltage-Min (Vsup) 4.5V
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
Pin Count 32
Base Part Number M29F010
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position QUAD
Voltage - Supply 4.5V~5.5V
Technology FLASH - NOR
Terminal Finish TIN LEAD
ECCN Code EAR99
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 32
Surface Mount YES
Package / Case 32-LCC (J-Lead)
Mounting Type Surface Mount
