M24C08-RDW6TP
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount M24C08 Tape & Reel (TR) ic memory 400kHz 900ns 3mm 800muA
PDF
/
Buying Options
Total Price: USD $0.19
Unit Price: USD $0.1936
≥1 USD $0.1936
≥10 USD $0.19008
≥100 USD $0.176704
≥500 USD $0.175824
≥1000 USD $0.1562
≥3000 USD $0.154176
Inventory: 29756
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 4.4mm
Height Seated (Max) 1.2mm
Technical
I2C Control Byte 1010DMMR
Write Protection HARDWARE
Data Retention Time-Min 40
Write Cycle Time-Max (tWC) 5 ms
Endurance 1000000 Write/Erase Cycles
Serial Bus Type I2C
Standby Current-Max 0.000001A
Density 8 kb
Write Cycle Time - Word, Page 5ms
Memory Width 8
Memory Interface I2C
Memory Format EEPROM
Access Time 900ns
Clock Frequency 400kHz
Memory Type Non-Volatile
Nominal Supply Current 800μA
Memory Size 8Kb 1K x 8
Interface 2-Wire, I2C, Serial
Power Supplies 2/5V
Supply Voltage-Max (Vsup) 5.5V
Operating Supply Voltage 6.5V
Pin Count 8
Base Part Number M24C08
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.65mm
Supply Voltage 2.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 1.8V~5.5V
Technology CMOS
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold, Tin
Supply Chain
Factory Lead Time 13 Weeks
