M24256-DFCS6TP/K
RoHS
RoHS compliant
RoHS compliantPackage 8-UFBGA, WLCSP
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount M24256 Tape & Reel (TR) ic memory 1MHz 450ns 1.271mm 2.5mA
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.281033
≥1 USD $0.281033
≥5000 USD $0.21
Inventory: 12414
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 1.271mm
Technical
I2C Control Byte 1010DDDR
Write Protection HARDWARE
Data Retention Time-Min 200
Endurance 4000000 Write/Erase Cycles
Serial Bus Type I2C
Standby Current-Max 0.000001A
Density 256 kb
Write Cycle Time - Word, Page 5ms
Memory Width 8
Memory Interface I2C
Memory Format EEPROM
Access Time 450ns
Clock Frequency 1MHz
Memory Type Non-Volatile
Nominal Supply Current 2.5mA
Memory Size 256Kb 32K x 8
Interface I2C, Serial
Supply Voltage-Min (Vsup) 1.7V
Supply Voltage-Max (Vsup) 5.5V
Base Part Number M24256
Supply Voltage 1.8V
Number of Functions 1
Terminal Position BOTTOM
Voltage - Supply 1.7V~5.5V
Technology CMOS
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Package / Case 8-UFBGA, WLCSP
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 6 Weeks
