BR25L010FJ-WE2
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount BR25L010 Tape & Reel (TR) ic memory 5MHz 5ms 3.9mm 0.000002A
PDF
/
Buying Options
Total Price: USD $0.45
Unit Price: USD $0.4488
≥1 USD $0.4488
≥10 USD $0.4092
≥100 USD $0.404096
≥500 USD $0.401632
≥1000 USD $0.359128
Inventory: 210
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2010
JESD-609 Code e2
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish TIN COPPER
HTS Code 8542.32.00.51
Technology CMOS
Voltage - Supply 1.8V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 10
Base Part Number BR25L010
Pin Count 8
JESD-30 Code R-PDSO-G8
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2/5V
Supply Voltage-Min (Vsup) 1.8V
Memory Size 1Kb 128 x 8
Memory Type Non-Volatile
Operating Mode SYNCHRONOUS
Clock Frequency 5MHz
Supply Current-Max 0.003mA
Memory Format EEPROM
Memory Interface SPI
Organization 128X8
Memory Width 8
Write Cycle Time - Word, Page 5ms
Standby Current-Max 0.000002A
Memory Density 1024 bit
Parallel/Serial SERIAL
Serial Bus Type SPI
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 5ms
Data Retention Time-Min 40
Write Protection HARDWARE
Dimensions
Height Seated (Max) 1.65mm
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
