BR24T128F-WE2
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description
e3 Surface Mount BR24T128 Tape & Reel (TR) ic memory 400kHz 900ns 4.4mm 0.000002A
PDF
/
Buying Options
Total Price: USD $0.58
Unit Price: USD $0.5808
≥1 USD $0.5808
≥10 USD $0.52536
≥100 USD $0.518848
≥500 USD $0.515856
≥1000 USD $0.461208
≥3000 USD $0.457318
Inventory: 309
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Plating Copper, Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.173, 4.40mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2011
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish Matte Tin (Sn)
Technology CMOS
Voltage - Supply 1.6V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 225
Number of Functions 1
Supply Voltage 2.5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number BR24T128
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 1.6V
Interface 2-Wire, I2C, Serial
Memory Size 128Kb 16K x 8
Memory Type Non-Volatile
Operating Mode SYNCHRONOUS
Clock Frequency 400kHz
Supply Current-Max 0.0025mA
Access Time 900 ns
Memory Format EEPROM
Memory Interface I2C
Memory Width 8
Write Cycle Time - Word, Page 5ms
Density 128 kb
Standby Current-Max 0.000002A
Serial Bus Type I2C
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 5ms
Data Retention Time-Min 40
Write Protection HARDWARE
I2C Control Byte 1010DDDR
Dimensions
Height Seated (Max) 1.71mm
Length 5mm
Width 4.4mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
