HYB25D512800CE-5
RoHS
/
Package 66-TSSOP (0.400, 10.16mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount Tape & Reel (TR) 64MX8 ic memory 200MHz 200mus 10.16mm 0.0046A
PDF
/
Buying Options
Total Price: USD $6.71
Unit Price: USD $6.7056
≥1 USD $6.7056
Inventory: 2463
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 10.16mm
Length 22.22mm
Height Seated (Max) 1.2mm
Technical
Interleaved Burst Length 248
Sequential Burst Length 248
Refresh Cycles 8192
I/O Type COMMON
Memory Density 536870912 bit
Standby Current-Max 0.0046A
Memory Width 8
Output Characteristics 3-STATE
Organization 64MX8
Memory Interface Parallel
Memory Format DRAM
Access Time 200 μs
Supply Current-Max 0.23mA
Clock Frequency 200MHz
Operating Mode SYNCHRONOUS
Memory Type Volatile
Number of Ports 1
Memory Size 512Mb 64M x 8
Supply Voltage-Min (Vsup) 2.3V
Power Supplies 2.6V
Supply Voltage-Max (Vsup) 2.7V
Qualification Status Not Qualified
Pin Count 66
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 2.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 2.3V~2.7V
Technology SDRAM - DDR
HTS Code 8542.32.00.28
Additional Feature AUTO/SELF REFRESH
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 66
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
JESD-609 Code e3
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 66
Surface Mount YES
Package / Case 66-TSSOP (0.400, 10.16mm Width)
Mounting Type Surface Mount
