SST49LF016C-33-4C-WHE
RoHS
RoHS compliant
RoHS compliantPackage 32-TFSOP (0.488, 12.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount SST49LF016C Tray ic memory 33MHz 11ns 8.1mm 18mA
PDF
/
Buying Options
Total Price: USD $12.57
Unit Price: USD $12.57325
≥1 USD $12.57325
≥10 USD $10.317
≥100 USD $9.994
≥500 USD $9.67195
≥1000 USD $9.3499
Inventory: 7310
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 32-TFSOP (0.488, 12.40mm Width)
Surface Mount YES
Number of Pins 32
Technical
Operating Temperature 0°C~85°C TA
Packaging Tray
Published 2000
Series SST49
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 32
ECCN Code EAR99
Terminal Finish MATTE TIN
Technology CMOS
Voltage - Supply 3V~3.6V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number SST49LF016C
Pin Count 32
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3V
Interface Parallel, SPI, Serial
Memory Size 16Mb 2M x 8
Nominal Supply Current 18mA
Memory Type Non-Volatile
Max Supply Current 18mA
Clock Frequency 33MHz
Access Time 11 ns
Memory Format FLASH
Memory Interface Parallel
Data Bus Width 8b
Organization 2MX8
Write Cycle Time - Word, Page 10μs
Address Bus Width 4b
Density 16 Mb
Standby Current-Max 0.0001A
Sync/Async Synchronous
Word Size 8b
Programming Voltage 3V
Data Polling NO
Toggle Bit NO
Number of Sectors/Size 12131
Page Size 128B
Ready/Busy YES
Boot Block TOP
Dimensions
Height 1.05mm
Length 12.5mm
Width 8.1mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
