SST39VF6401B-70-4C-EKE
RoHS
RoHS compliant
RoHS compliantPackage 48-TFSOP (0.724, 18.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description
3A991.B.1.A Surface Mount SST39VF6401B Tray ic memory 70ns 12.2mm 18mA 64Mb
PDF
/
Buying Options
Total Price: USD $7.73
Unit Price: USD $7.7264
≥1 USD $7.7264
≥10 USD $7.43248
≥100 USD $7.151496
Inventory: 206
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 12.2mm
Length 18.5mm
Height 1.05mm
Technical
Common Flash Interface YES
Boot Block BOTTOM
Sector Size 2K
Number of Sectors/Size 2K
Command User Interface YES
Toggle Bit YES
Data Polling YES
Programming Voltage 2.7V
Word Size 16b
Sync/Async Asynchronous
Standby Current-Max 0.00002A
Density 64 Mb
Address Bus Width 22b
Write Cycle Time - Word, Page 10μs
Organization 4MX16
Data Bus Width 16b
Memory Interface Parallel
Memory Format FLASH
Access Time 70ns
Max Supply Current 18mA
Memory Type Non-Volatile
Nominal Supply Current 18mA
Memory Size 64Mb 4M x 16
Supply Voltage-Min (Vsup) 2.7V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Pin Count 48
Base Part Number SST39VF6401B
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.5mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 2.7V~3.6V
Technology CMOS
HTS Code 8542.32.00.51
Additional Feature BOTTOM BOOT BLOCK
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code 3A991.B.1.A
Termination SMD/SMT
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SST39 MPF?
Published 2000
Packaging Tray
Operating Temperature 0°C~70°C TA
Physical
Weight 19.986414mg
Number of Pins 48
Surface Mount YES
Package / Case 48-TFSOP (0.724, 18.40mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
