SST39VF402C-70-4C-MAQE
RoHS
RoHS compliant
RoHS compliantPackage 48-WFBGA
Category Integrated Circuits (ICs) / Memory
Description
Asynchronous Active TOP 2011 FLASH Memory 0C~70C TA 2.7V 4Mb 18mA
PDF
/
Buying Options
Total Price: USD $1.35
Unit Price: USD $1.349661
≥1 USD $1.349661
≥200 USD $0.522534
≥740 USD $0.504154
≥1480 USD $0.494963
Inventory: 3690
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 6mm
Height Seated (Max) 0.73mm
Technical
Common Flash Interface YES
Boot Block TOP
Ready/Busy YES
Sector Size 2K
Number of Sectors/Size 128
Command User Interface YES
Toggle Bit YES
Data Polling YES
Programming Voltage 2.7V
Word Size 16b
Sync/Async Asynchronous
Standby Current-Max 0.00002A
Density 4 Mb
Address Bus Width 1b
Write Cycle Time - Word, Page 10μs
Memory Width 16
Organization 256KX16
Memory Interface Parallel
Memory Format FLASH
Access Time 70ns
Memory Type Non-Volatile
Nominal Supply Current 18mA
Memory Size 4Mb 256K x 16
Supply Voltage-Min (Vsup) 2.7V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Pin Count 48
Base Part Number SST39VF402C
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.5mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position BOTTOM
Voltage - Supply 2.7V~3.6V
Technology CMOS
HTS Code 8542.32.00.51
Additional Feature TOP BOOT BLOCK
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e1
Series SST39 MPF?
Published 2011
Packaging Tray
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 48
Package / Case 48-WFBGA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
