SST39VF020-70-4C-WHE
RoHS
RoHS compliant
RoHS compliantPackage 32-TFSOP (0.488, 12.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description
3A991.B.1.A Surface Mount SST39VF020 Tray ic memory 70ns 12.4mm 20mA 2Mb
PDF
/
Buying Options
Total Price: USD $1.33
Unit Price: USD $1.3288
≥1 USD $1.3288
≥10 USD $1.287264
≥100 USD $1.241768
Inventory: 577
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Plating Tin
Mounting Type Surface Mount
Package / Case 32-TFSOP (0.488, 12.40mm Width)
Surface Mount YES
Number of Pins 32
Technical
Operating Temperature 0°C~70°C TA
Packaging Tray
Published 2000
Series SST39 MPF?
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 32
Termination SMD/SMT
ECCN Code 3A991.B.1.A
Technology CMOS
Voltage - Supply 2.7V~3.6V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number SST39VF020
Pin Count 32
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Sector Size 4K
Number of Sectors/Size 64
Command User Interface YES
Toggle Bit YES
Data Polling YES
Programming Voltage 2.7V
Word Size 8b
Sync/Async Asynchronous
Standby Current-Max 0.000015A
Density 2 Mb
Address Bus Width 18b
Write Cycle Time - Word, Page 20μs
Memory Width 8
Organization 256KX8
Data Bus Width 8b
Memory Interface Parallel
Memory Format FLASH
Access Time 70ns
Memory Type Non-Volatile
Nominal Supply Current 20mA
Memory Size 2Mb 256K x 8
Supply Voltage-Min (Vsup) 2.7V
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 12.4mm
Height Seated (Max) 1.2mm
