SST39LF040-55-4C-WHE-T
RoHS
RoHS compliant
RoHS compliantPackage 32-TFSOP (0.488, 12.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description
Surface Mount SST39LF040 Tape & Reel (TR) 512KX8 ic memory 55ns 12.4mm 20mA 4Mb
PDF
/
Buying Options
Total Price: USD $1.59
Unit Price: USD $1.591531
≥1 USD $1.591531
≥10 USD $1.501441
≥100 USD $1.416456
≥500 USD $1.336283
≥1000 USD $1.260644
Inventory: 4884
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 12.4mm
Height Seated (Max) 1.2mm
Technical
Programming Voltage 3V
Density 4 Mb
Address Bus Width 19b
Write Cycle Time - Word, Page 20μs
Memory Width 8
Organization 512KX8
Data Bus Width 8b
Memory Interface Parallel
Memory Format FLASH
Access Time 55ns
Max Supply Current 20mA
Memory Type Non-Volatile
Memory Size 4Mb 512K x 8
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
Base Part Number SST39LF040
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Technology CMOS
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Series SST39 MPF?
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 32
Surface Mount YES
Package / Case 32-TFSOP (0.488, 12.40mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
