SST38VF6401B-70I/TV
RoHS
RoHS compliant
RoHS compliantPackage 48-TFSOP (0.724, 18.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description
e3 Surface Mount SST38VF6401 Tray ic memory 70ns 18.4mm 0.00004A 64Mb
PDF
/
Buying Options
Total Price: USD $7.51
Unit Price: USD $7.5064
≥1 USD $7.5064
≥10 USD $7.224096
≥100 USD $6.952088
Inventory: 184
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type Surface Mount
Package / Case 48-TFSOP (0.724, 18.40mm Width)
Surface Mount YES
Number of Pins 48
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Published 2013
Series SST38
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 48
Terminal Finish Matte Tin (Sn) - annealed
Technology CMOS
Voltage - Supply 2.7V~3.6V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number SST38VF6401
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2.7V
Memory Size 64Mb 4M x 16
Memory Type Non-Volatile
Supply Current-Max 0.05mA
Access Time 70ns
Memory Format FLASH
Memory Interface Parallel
Organization 4MX16
Memory Width 16
Write Cycle Time - Word, Page 10μs
Address Bus Width 22b
Density 64 Mb
Standby Current-Max 0.00004A
Programming Voltage 2.7V
Data Polling YES
Toggle Bit YES
Command User Interface NO
Number of Sectors/Size 128
Sector Size 32K
Page Size 16B
Ready/Busy YES
Boot Block BOTTOM
Common Flash Interface YES
Dimensions
Height Seated (Max) 1.2mm
Length 18.4mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
