SST26WF080BT-104I/MF
RoHS
RoHS compliant
RoHS compliantPackage 8-WDFN Exposed Pad
Category Integrated Circuits (ICs) / Memory
Description
R-PDSO-N8 Surface Mount SST26WF080 Tape & Reel (TR) ic memory 104MHz 1.5ms 5mm 83886080bit
PDF
/
Inventory: 1613
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 6mm
Height Seated (Max) 0.8mm
Technical
Programming Voltage 1.8V
Parallel/Serial SERIAL
Screening Level TS 16949
Memory Density 83886080 bit
Write Cycle Time - Word, Page 1.5ms
Memory Width 1
Organization 80MX1
Memory Interface SPI - Quad I/O
Memory Format FLASH
Clock Frequency 104MHz
Operating Mode SYNCHRONOUS
Memory Type Non-Volatile
Memory Size 8Mb 1M x 8
Interface SPI
Supply Voltage-Min (Vsup) 1.65V
Supply Voltage-Max (Vsup) 1.95V
JESD-30 Code R-PDSO-N8
Base Part Number SST26WF080
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1.27mm
Supply Voltage 1.8V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 1.65V~1.95V
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Series SST26 SQI?
Published 2014
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 8-WDFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
