SST26WF040BA-104I/MF
RoHS
RoHS compliant
RoHS compliantPackage 8-WDFN Exposed Pad
Category Integrated Circuits (ICs) / Memory
Description
R-PDSO-N8 Surface Mount SST26WF040 Tube ic memory 104MHz 1.5ms 5mm 4194304bit
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.28486
≥1 USD $0.28486
≥10 USD $0.229719
≥30 USD $0.206086
≥100 USD $0.176598
≥500 USD $0.163469
≥1000 USD $0.155592
Inventory: 1605
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type Surface Mount
Package / Case 8-WDFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2014
Series SST26 SQI?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
Terminal Finish Matte Tin (Sn) - annealed
Technology CMOS
Voltage - Supply 1.65V~1.95V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 1.8V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number SST26WF040
JESD-30 Code R-PDSO-N8
Supply Voltage-Max (Vsup) 1.95V
Supply Voltage-Min (Vsup) 1.65V
Interface SPI
Memory Size 4Mb 512K x 8
Memory Type Non-Volatile
Operating Mode SYNCHRONOUS
Clock Frequency 104MHz
Memory Format FLASH
Memory Interface SPI - Quad I/O
Organization 4MX1
Memory Width 1
Write Cycle Time - Word, Page 1.5ms
Memory Density 4194304 bit
Screening Level TS 16949
Parallel/Serial SERIAL
Programming Voltage 1.8V
Dimensions
Height Seated (Max) 0.8mm
Length 6mm
Width 5mm
Compliance
RoHS Status ROHS3 Compliant
