SST26VF016BT-104I/SN
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
3A991.B.1.A Surface Mount SST26VF016B Tape & Reel (TR) ic memory 104MHz 1.5ms 3.9mm 0.000025A
PDF
/
Buying Options
Total Price: USD $1.52
Unit Price: USD $1.5224
≥1 USD $1.5224
≥10 USD $1.477344
≥100 USD $1.413984
Inventory: 9617
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Reverse Pinout NO
Boot Block BOTTOM/TOP
Page Size 256B
Write Protection HARDWARE/SOFTWARE
Data Retention Time-Min 100
Endurance 100000 Write/Erase Cycles
Serial Bus Type SPI
Programming Voltage 2.7V
Standby Current-Max 0.000025A
Density 16 Mb
Write Cycle Time - Word, Page 1.5ms
Memory Width 1
Organization 16MX1
Memory Interface SPI - Quad I/O
Memory Format FLASH
Supply Current-Max 0.025mA
Clock Frequency 104MHz
Operating Mode SYNCHRONOUS
Memory Type Non-Volatile
Memory Size 16Mb 2M x 8
Interface SPI, Serial
Supply Voltage-Min (Vsup) 2.7V
Supply Voltage-Max (Vsup) 3.6V
Base Part Number SST26VF016B
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 2.7V~3.6V
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code 3A991.B.1.A
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series SST26 SQI?
Published 2014
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
