SST25WF040B-40I/SN
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
e3 Surface Mount SST25WF040 Tube ic memory 40MHz 1ms 3.9mm 4mA
PDF
/
Buying Options
Total Price: USD $0.96
Unit Price: USD $0.9592
≥1 USD $0.9592
≥10 USD $0.933504
≥100 USD $0.9064
Inventory: 999
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2006
Series SST25
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish Matte Tin (Sn) - annealed
Technology CMOS
Voltage - Supply 1.65V~1.95V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 1.8V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number SST25WF040
Operating Supply Voltage 1.8V
Supply Voltage-Max (Vsup) 1.95V
Supply Voltage-Min (Vsup) 1.65V
Page Size 256B
Density 4 Mb
Write Cycle Time - Word, Page 1ms
Organization 4MX1
Memory Interface SPI
Memory Format FLASH
Clock Frequency 40MHz
Memory Type Non-Volatile
Nominal Supply Current 4mA
Memory Size 4Mb 512K x 8
Interface SPI, Serial
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Height 1.25mm
