SST25WF020-40-5I-SAF
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
3A991.B.1.A Surface Mount SST25WF020 Tube ic memory 40MHz 9ns 4.9mm 10mA
PDF
/
Buying Options
Total Price: USD $9.42
Unit Price: USD $9.424
≥1 USD $9.424
≥10 USD $7.73205
≥100 USD $7.49075
≥500 USD $7.24945
≥1000 USD $7.0072
Inventory: 10010
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Data Retention Time-Min 100
Endurance 100000 Write/Erase Cycles
Serial Bus Type SPI
Word Size 8b
Sync/Async Synchronous
Density 2 Mb
Address Bus Width 1b
Write Cycle Time - Word, Page 60μs
Memory Width 8
Data Bus Width 8b
Memory Interface SPI
Memory Format FLASH
Access Time 9 ns
Clock Frequency 40MHz
Memory Type Non-Volatile
Nominal Supply Current 10mA
Memory Size 2Mb 256K x 8
Interface SPI, Serial
Supply Voltage-Min (Vsup) 1.65V
Supply Voltage-Max (Vsup) 1.95V
Operating Supply Voltage 1.8V
Pin Count 8
Base Part Number SST25WF020
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Supply Voltage 1.8V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 1.65V~1.95V
Technology CMOS
Terminal Finish NICKEL PALLADIUM GOLD
ECCN Code 3A991.B.1.A
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series SST25
Published 2005
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
