SST25VF040B-80-4I-S2AE-T

Microchip Technology
RoHS
RoHS RoHS compliant
Package 8-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Memory
Description EAR99 Surface Mount SST25VF040B Tape & Reel (TR) ic memory 80MHz 8ns 1.27mm 20mA
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥100 USD $2.13465
≥500 USD $2.0653
≥1000 USD $1.9969
Inventory: 35907
Minimum: 1
-
+

Technical Details

Physical

Mounting Type Surface Mount
Package / Case 8-SOIC (0.209, 5.30mm Width)
Surface Mount YES
Number of Pins 8

Technical

Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2005
Series SST25
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Technology CMOS
Voltage - Supply 2.7V~3.6V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number SST25VF040B
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2.7V
Interface SPI, Serial
Memory Size 4Mb 512K x 8
Nominal Supply Current 20mA
Memory Type Non-Volatile
Clock Frequency 80MHz
Access Time 8 ns
Memory Format FLASH
Memory Interface SPI
Data Bus Width 8b
Organization 4MX1
Memory Width 1
Write Cycle Time - Word, Page 10μs
Address Bus Width 1b
Density 4 Mb
Standby Current-Max 0.00002A
Sync/Async Synchronous
Word Size 8b
Serial Bus Type SPI
Endurance 100000 Write/Erase Cycles
Data Retention Time-Min 100
Write Protection HARDWARE/SOFTWARE

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
