SST25VF040B-50-4I-SAE-T

Microchip Technology
RoHS
RoHS RoHS compliant
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description e3 Surface Mount SST25VF040B Tape & Reel (TR) ic memory 50MHz 8ns 3.9mm 4Mb
PDF
/
Buying Options
Total Price: USD $1.11
Unit Price: USD $1.1088
≥1 USD $1.1088
≥10 USD $1.051424
≥100 USD $1.015168
Inventory: 36209
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm

Technical

Programming Voltage 2.7V
Density 4 Mb
Write Cycle Time - Word, Page 10μs
Memory Width 1
Organization 4MX1
Memory Interface SPI
Memory Format FLASH
Access Time 8 ns
Clock Frequency 50MHz
Memory Type Non-Volatile
Memory Size 4Mb 512K x 8
Interface SPI, Serial
Supply Voltage-Min (Vsup) 2.7V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Base Part Number SST25VF040B
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 2.7V~3.6V
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Series SST25
Published 1998
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA

Physical

Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 10 Weeks
