SST25VF020B-80-4I-QAE-T
RoHS
RoHS compliant
RoHS compliantPackage 8-WDFN Exposed Pad
Category Integrated Circuits (ICs) / Memory
Description
3A991.B.1.A Surface Mount SST25VF020B Tape & Reel (TR) ic memory 80MHz 6ns 6mm 20mA
PDF
/
Buying Options
Total Price: USD $1.38
Unit Price: USD $1.3832
≥1 USD $1.3832
≥10 USD $1.13525
≥100 USD $1.09915
≥500 USD $1.064
≥1000 USD $1.02885
Inventory: 3213
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 6mm
Technical
Write Protection HARDWARE/SOFTWARE
Data Retention Time-Min 100
Endurance 100000 Write/Erase Cycles
Serial Bus Type SPI
Programming Voltage 2.7V
Word Size 8b
Sync/Async Synchronous
Standby Current-Max 0.00002A
Density 2 Mb
Address Bus Width 1b
Write Cycle Time - Word, Page 10μs
Memory Width 8
Data Bus Width 8b
Memory Interface SPI
Memory Format FLASH
Access Time 6 ns
Clock Frequency 80MHz
Memory Type Non-Volatile
Nominal Supply Current 20mA
Memory Size 2Mb 256K x 8
Interface SPI, Serial
Supply Voltage-Min (Vsup) 2.7V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Base Part Number SST25VF020B
Terminal Pitch 1.27mm
Supply Voltage 3V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 2.7V~3.6V
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code 3A991.B.1.A
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SST25
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Package / Case 8-WDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
