AT93C56B-SSHM-T
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
e4 Surface Mount AT93C56B Tape & Reel (TR) ic memory 2MHz 5ms 3.99mm 2mA
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.264
≥1 USD $0.264
≥10 USD $0.24464
≥100 USD $0.237952
Inventory: 3813
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 25 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2005
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature ALSO OPERATES WITH 1.7V-5.5V AND 2.5V-5.5V SUPPLY
Technology CMOS
Voltage - Supply 1.7V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number AT93C56B
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Interface Serial
Memory Size 2Kb 256 x 8 128 x 16
Nominal Supply Current 2mA
Memory Type Non-Volatile
Clock Frequency 2MHz
Memory Format EEPROM
Memory Interface SPI
Write Cycle Time - Word, Page 5ms
Density 2 kb
Standby Current-Max 0.000001A
Serial Bus Type MICROWIRE
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 5ms
Data Retention Time-Min 100
Write Protection SOFTWARE
Dimensions
Height 1.5mm
Length 5.05mm
Width 3.99mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
