AT28HC64BF-12SU
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Memory
Description
R-PDSO-G28 Surface Mount AT28HC64 Tube ic memory 120ns 7.5mm 40mA 64kb
PDF
/
Buying Options
Total Price: USD $6.12
Unit Price: USD $6.1248
≥1 USD $6.1248
≥10 USD $5.891776
≥100 USD $5.665
Inventory: 75
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-SOIC (0.295, 7.50mm Width)
Number of Pins 32
Technical
Operating Temperature -40°C~85°C TC
Packaging Tube
Published 1997
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 28
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 250
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number AT28HC64
JESD-30 Code R-PDSO-G28
Operating Supply Voltage 5V
Power Supplies 5V
Memory Size 64Kb 8K x 8
Nominal Supply Current 40mA
Memory Type Non-Volatile
Access Time 120ns
Memory Format EEPROM
Memory Interface Parallel
Organization 8KX8
Memory Width 8
Write Cycle Time - Word, Page 10ms
Density 64 kb
Standby Current-Max 0.0001A
Programming Voltage 5V
Endurance 100000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 2ms
Data Polling YES
Toggle Bit YES
Command User Interface NO
Page Size 64words
Dimensions
Height Seated (Max) 2.65mm
Length 17.9mm
Width 7.5mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
