AT24C32W-10SI
RoHS
/
Package 8-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount AT24C32 Tube ic memory 400kHz 900ns 5.27mm 1e-7A
PDF
/
Buying Options
Total Price: USD $3.56
Unit Price: USD $3.557959
≥1 USD $3.557959
≥188 USD $1.420558
≥470 USD $1.371981
≥1034 USD $1.349661
Inventory: 8363
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.209, 5.30mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 1998
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish TIN LEAD
Additional Feature DATA RETENTION: 100 YEARS
HTS Code 8542.32.00.51
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 2.5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number AT24C32
JESD-30 Code R-PDSO-G8
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2/5V
Supply Voltage-Min (Vsup) 1.8V
Memory Size 32Kb 4K x 8
Memory Type Non-Volatile
Operating Mode SYNCHRONOUS
Clock Frequency 400kHz
Supply Current-Max 0.003mA
Access Time 900ns
Memory Format EEPROM
Memory Interface I2C
Organization 4KX8
Output Characteristics OPEN-DRAIN
Memory Width 8
Write Cycle Time - Word, Page 10ms
Standby Current-Max 1e-7A
Memory Density 32768 bit
Parallel/Serial SERIAL
Serial Bus Type I2C
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 20ms
Data Retention Time-Min 100
Write Protection HARDWARE
I2C Control Byte 1010DDDR
Dimensions
Height Seated (Max) 2.03mm
Length 5.31mm
Width 5.27mm
Compliance
RoHS Status Non-RoHS Compliant
