AT24C256C-MAPD-E
RoHS
/
Package 8-UFDFN Exposed Pad
Category Integrated Circuits (ICs) / Memory
Description
Active I2C SERIAL DUAL EEPROM Memory -40C~125C TA 2.5V 262144bit 2mm
PDF
/
Inventory: 1147
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-UFDFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q100
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
Technology CMOS
Voltage - Supply 2.5V~5.5V
Terminal Position DUAL
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.5mm
Reach Compliance Code compliant
Base Part Number AT24C256C
JESD-30 Code R-PDSO-N8
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.5V
Memory Size 256Kb 32K x 8
Memory Type Non-Volatile
Operating Mode SYNCHRONOUS
Clock Frequency 400kHz
Access Time 900ns
Memory Format EEPROM
Memory Interface I2C
Organization 32KX8
Memory Width 8
Write Cycle Time - Word, Page 5ms
Memory Density 262144 bit
Parallel/Serial SERIAL
Serial Bus Type I2C
Dimensions
Height Seated (Max) 0.6mm
Length 3mm
Width 2mm
