AT24C04C-XHM-B
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description
e4 Surface Mount AT24C04 Tube ic memory 1MHz 550ns 4.5mm 3mA
PDF
/
Buying Options
Total Price: USD $0.23
Unit Price: USD $0.2288
≥1 USD $0.2288
≥10 USD $0.22
Inventory: 17113
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 1997
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology CMOS
Voltage - Supply 1.7V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number AT24C04
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 1.7V
Interface 2-Wire, I2C, Serial
Memory Size 4Kb 512 x 8
Nominal Supply Current 3mA
Memory Type Non-Volatile
Clock Frequency 1MHz
Access Time 550ns
Memory Format EEPROM
Memory Interface I2C
Write Cycle Time - Word, Page 5ms
Density 4 kb
Serial Bus Type I2C
Write Cycle Time-Max (tWC) 5ms
Dimensions
Height 1.05mm
Length 3.1mm
Width 4.5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
