AT24C04C-MAPD-T

Microchip Technology
RoHS
/
Package 8-UFDFN Exposed Pad
Category Integrated Circuits (ICs) / Memory
Description Active I2C SERIAL DUAL EEPROM Memory -40C~125C TA 2.5V 4096bit 2mm
PDF
/
Inventory: 1629
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Surface Mount
Package / Case 8-UFDFN Exposed Pad
Surface Mount YES

Technical

Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q100
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
Technology CMOS
Voltage - Supply 2.5V~5.5V
Terminal Position DUAL
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.5mm
Reach Compliance Code compliant
Base Part Number AT24C04
JESD-30 Code R-PDSO-N8
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.5V
Memory Size 4Kb 512 x 8
Memory Type Non-Volatile
Operating Mode SYNCHRONOUS
Clock Frequency 400kHz
Access Time 900ns
Memory Format EEPROM
Memory Interface I2C
Organization 512X8
Memory Width 8
Write Cycle Time - Word, Page 5ms
Memory Density 4096 bit
Parallel/Serial SERIAL
Serial Bus Type I2C
Write Cycle Time-Max (tWC) 5ms

Dimensions

Height Seated (Max) 0.6mm
Length 3mm
Width 2mm
