AT24C04C-MAPD-E
RoHS
/
Package 8-UFDFN Exposed Pad
Category Integrated Circuits (ICs) / Memory
Description
R-PDSO-N8 Surface Mount AT24C04 Tape & Reel (TR) ic memory 400kHz 900ns 2mm 4096bit
PDF
/
Inventory: 1451
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Width 2mm
Length 3mm
Height Seated (Max) 0.6mm
Technical
Write Cycle Time-Max (tWC) 5ms
Serial Bus Type I2C
Parallel/Serial SERIAL
Memory Density 4096 bit
Write Cycle Time - Word, Page 5ms
Memory Width 8
Organization 512X8
Memory Interface I2C
Memory Format EEPROM
Access Time 900ns
Clock Frequency 400kHz
Operating Mode SYNCHRONOUS
Memory Type Non-Volatile
Memory Size 4Kb 512 x 8
Supply Voltage-Min (Vsup) 2.5V
Supply Voltage-Max (Vsup) 5.5V
JESD-30 Code R-PDSO-N8
Base Part Number AT24C04
Reach Compliance Code compliant
Terminal Pitch 0.5mm
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 2.5V~5.5V
Technology CMOS
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Surface Mount YES
Package / Case 8-UFDFN Exposed Pad
Mounting Type Surface Mount
