AT24C01B-TH-T
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description
Surface Mount AT24C01 Tape & Reel (TR) CMOS ic memory 1MHz 550ns 3mm 3mA
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.37035
≥1 USD $5.37035
≥10 USD $4.4061
≥100 USD $4.26835
≥500 USD $4.1306
≥1000 USD $3.99285
Inventory: 10006
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2004
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Technology CMOS
Voltage - Supply 1.8V~5.5V
Terminal Position DUAL
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.65mm
Base Part Number AT24C01
Operating Supply Voltage 5V
Interface 2-Wire, I2C, Serial
Memory Size 1Kb 128 x 8
Nominal Supply Current 3mA
Memory Type Non-Volatile
Clock Frequency 1MHz
Access Time 550ns
Memory Format EEPROM
Memory Interface I2C
Memory Width 8
Write Cycle Time - Word, Page 5ms
Density 1 kb
Serial Bus Type I2C
Write Cycle Time-Max (tWC) 5ms
Dimensions
Height Seated (Max) 1.2mm
Length 4.4mm
Width 3mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
