AT21CS01-SSHM15-T
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
Active 1-WIRE SERIAL 2014 EEPROM Memory -40C~85C TC 1.7V 1024bit 3.9mm
PDF
/
Inventory: 1348
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Write Cycle Time-Max (tWC) 5ms
Serial Bus Type 1-WIRE
Parallel/Serial SERIAL
Memory Density 1024 bit
Write Cycle Time - Word, Page 5ms
Memory Width 8
Memory Interface I2C, Single Wire
Memory Format EEPROM
Clock Frequency 125kHz
Operating Mode SYNCHRONOUS
Memory Type Non-Volatile
Memory Size 1Kb 128 x 8
Supply Voltage-Min (Vsup) 1.7V
Supply Voltage-Max (Vsup) 3.6V
Base Part Number AT21CS01
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Supply Voltage 1.8V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 1.7V~3.6V
Technology CMOS
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Published 2014
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TC
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
