93LC76B-I/ST
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 93LC76B Tube ic memory 3MHz 5ms 3mm 3mA
PDF
/
Inventory: 1166
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 4.4mm
Height Seated (Max) 1.1mm
Technical
Alternate Memory Width 8
Write Cycle Time-Max (tWC) 5ms
Serial Bus Type MICROWIRE
Density 8 kb
Write Cycle Time - Word, Page 5ms
Memory Width 16
Organization 512X16
Memory Interface SPI
Memory Format EEPROM
Clock Frequency 3MHz
Memory Type Non-Volatile
Nominal Supply Current 3mA
Memory Size 8Kb 512 x 16
Interface Serial
Supply Voltage-Min (Vsup) 2.5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 8
Base Part Number 93LC76B
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 2.5V~5.5V
Technology CMOS
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2012
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
