93LC76B-E/P
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Memory
Description
SOFTWARE Active MICROWIRE 2012 EEPROM Memory -40C~125C TA 3/5V 8kb 3mA
PDF
/
Inventory: 1181
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Memory Width 8
Write Cycle Time - Word, Page 5ms
Density 8 kb
Standby Current-Max 0.000005A
Serial Bus Type MICROWIRE
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 6ms
Data Retention Time-Min 200
Write Protection SOFTWARE
Alternate Memory Width 8
Memory Interface SPI
Memory Format EEPROM
Clock Frequency 3MHz
Memory Type Non-Volatile
Nominal Supply Current 3mA
Memory Size 8Kb 512 x 16
Interface Serial
Power Supplies 3/5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 8
Base Part Number 93LC76B
Terminal Pitch 2.54mm
Supply Voltage 2.5V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 2.5V~5.5V
Technology CMOS
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2012
Packaging Tube
Operating Temperature -40°C~125°C TA
Dimensions
Height Seated (Max) 4.32mm
Length 9.46mm
Width 7.62mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Physical
Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 14 Weeks
