93LC66AXT-E/SN
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
SOFTWARE Active Tin MICROWIRE EEPROM Memory -40C~125C TA 2.5V 4kb 2mA
PDF
/
Inventory: 1540
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Published 2008
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Technology CMOS
Voltage - Supply 2.5V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 93LC66A
Pin Count 8
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3/5V
Supply Voltage-Min (Vsup) 2.5V
Interface Serial
Memory Size 4Kb 512 x 8
Nominal Supply Current 2mA
Memory Type Non-Volatile
Clock Frequency 2MHz
Access Time 250 ns
Memory Format EEPROM
Memory Interface SPI
Memory Width 8
Write Cycle Time - Word, Page 6ms
Density 4 kb
Standby Current-Max 0.000005A
Serial Bus Type MICROWIRE
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 6ms
Data Retention Time-Min 200
Write Protection SOFTWARE
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
