93LC46C-I/P
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Through Hole 93LC46C Tube ic memory 3MHz 200ns 7.87mm 2mA
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.3696
≥1 USD $0.3696
≥10 USD $0.3608
≥100 USD $0.3432
Inventory: 1252
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 7.87mm
Length 9.27mm
Height 3.3mm
Technical
Write Protection SOFTWARE
Data Retention Time-Min 200
Write Cycle Time-Max (tWC) 6ms
Endurance 1000000 Write/Erase Cycles
Serial Bus Type MICROWIRE
Standby Current-Max 0.000001A
Density 1 kb
Write Cycle Time - Word, Page 6ms
Organization 64X16
Memory Interface SPI
Memory Format EEPROM
Access Time 200 ns
Clock Frequency 3MHz
Memory Type Non-Volatile
Nominal Supply Current 2mA
Memory Size 1Kb 128 x 8 64 x 16
Interface Serial
Supply Voltage-Min (Vsup) 2.5V
Power Supplies 3/5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 8
Base Part Number 93LC46C
Terminal Pitch 2.54mm
Supply Voltage 3V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 2.5V~5.5V
Technology CMOS
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2004
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 7 Weeks
Alternative Model
