93C76AT-E/OT
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6
Category Integrated Circuits (ICs) / Memory
Description
e3 Surface Mount 93C76A Tape & Reel (TR) ic memory 3MHz 100ns 2.95mm 3mA
PDF
/
Buying Options
Total Price: USD $0.86
Unit Price: USD $0.85975
≥1 USD $0.85975
≥10 USD $0.7049
≥100 USD $0.68305
≥500 USD $0.6612
≥1000 USD $0.63935
Inventory: 11004
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 2.95mm
Height Seated (Max) 1.45mm
Technical
Write Protection SOFTWARE
Data Retention Time-Min 200
Write Cycle Time-Max (tWC) 2ms
Endurance 1000000 Write/Erase Cycles
Serial Bus Type MICROWIRE
Standby Current-Max 0.000005A
Density 8 kb
Write Cycle Time - Word, Page 2ms
Memory Width 8
Organization 1KX8
Memory Interface SPI
Memory Format EEPROM
Access Time 100 ns
Clock Frequency 3MHz
Memory Type Non-Volatile
Nominal Supply Current 3mA
Memory Size 8Kb 1K x 8
Interface Serial
Power Supplies 5V
Operating Supply Voltage 5V
Pin Count 6
Base Part Number 93C76A
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.95mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Terminal Finish Matte Tin (Sn)
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 6
Package / Case SOT-23-6
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
