93C56AT-E/SN
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
e3 Surface Mount 93C56A Tape & Reel (TR) ic memory 2MHz 250ns 3.9mm 2mA
PDF
/
Buying Options
Total Price: USD $0.59
Unit Price: USD $0.5909
≥1 USD $0.5909
≥10 USD $0.48545
≥100 USD $0.47025
≥500 USD $0.45505
≥1000 USD $0.43985
Inventory: 5439
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Published 2011
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Additional Feature 1000K ERASE/WRITE CYCLES; DATA RETENTION > 200 YEARS
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 93C56A
Pin Count 8
Operating Supply Voltage 5V
Power Supplies 5V
Interface Serial
Memory Size 2Kb 256 x 8
Nominal Supply Current 2mA
Memory Type Non-Volatile
Clock Frequency 2MHz
Access Time 250 ns
Memory Format EEPROM
Memory Interface SPI
Memory Width 8
Write Cycle Time - Word, Page 2ms
Density 2 kb
Standby Current-Max 0.000005A
Serial Bus Type MICROWIRE
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 2ms
Data Retention Time-Min 200
Write Protection SOFTWARE
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
