93C46BXT-E/SN
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
SOFTWARE Active Tin MICROWIRE EEPROM Memory -40C~125C TA 5V 1kb 2mA
PDF
/
Buying Options
Total Price: USD $0.34
Unit Price: USD $0.340986
≥1 USD $0.340986
≥200 USD $0.13196
≥500 USD $0.127325
≥1000 USD $0.125028
Inventory: 9439
Minimum: 1
-
+
Technical Details
Technical
Standby Current-Max 0.000005A
Serial Bus Type MICROWIRE
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 6ms
Data Retention Time-Min 200
Write Protection SOFTWARE
Density 1 kb
Write Cycle Time - Word, Page 2ms
Memory Width 16
Organization 64X16
Memory Interface SPI
Memory Format EEPROM
Access Time 250 ns
Clock Frequency 2MHz
Memory Type Non-Volatile
Nominal Supply Current 2mA
Memory Size 1Kb 64 x 16
Interface Serial
Power Supplies 5V
Operating Supply Voltage 5V
Pin Count 8
Base Part Number 93C46B
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Additional Feature 1000000 ERASE/WRITE CYCLES; DATA RETENTION > 200 YEARS
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 6 Weeks
