93AA86BT-I/SN
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 93AA86B Tape & Reel (TR) ic memory 3MHz 100ns 3.9mm 3mA
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.07445
≥1 USD $1.07445
≥10 USD $0.8816
≥100 USD $0.85405
≥500 USD $0.8265
≥1000 USD $0.79895
≥1000 USD $0.7163
Inventory: 428
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Write Protection SOFTWARE
Data Retention Time-Min 200
Write Cycle Time-Max (tWC) 6ms
Endurance 1000000 Write/Erase Cycles
Serial Bus Type MICROWIRE
Standby Current-Max 0.000001A
Density 16 kb
Write Cycle Time - Word, Page 5ms
Memory Width 16
Organization 1KX16
Memory Interface SPI
Memory Format EEPROM
Access Time 100 ns
Clock Frequency 3MHz
Operating Mode SYNCHRONOUS
Memory Type Non-Volatile
Nominal Supply Current 3mA
Memory Size 16Kb 1K x 16
Interface Serial
Operating Supply Voltage 5V
Qualification Status Not Qualified
Pin Count 8
Base Part Number 93AA86B
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Supply Voltage 2.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 1.8V~5.5V
Technology CMOS
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 6 Weeks
