93AA46BT-I/OT
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6
Category Integrated Circuits (ICs) / Memory
Description
e3 Surface Mount 93AA46B Tape & Reel (TR) ic memory 2MHz 250ns 2.95mm 2mA
PDF
/
Buying Options
Total Price: USD $0.24
Unit Price: USD $0.2376
≥1 USD $0.2376
≥10 USD $0.2266
Inventory: 4916
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SOT-23-6
Number of Pins 6
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2008
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Termination SMD/SMT
Terminal Finish Matte Tin (Sn)
Technology CMOS
Voltage - Supply 1.8V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.5V
Terminal Pitch 0.95mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 93AA46B
Pin Count 6
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2/5V
Supply Voltage-Min (Vsup) 1.8V
Interface Serial
Memory Size 1Kb 64 x 16
Nominal Supply Current 2mA
Memory Type Non-Volatile
Clock Frequency 2MHz
Access Time 250 ns
Memory Format EEPROM
Memory Interface SPI
Organization 128X8
Memory Width 8
Write Cycle Time - Word, Page 6ms
Density 1 kb
Standby Current-Max 0.000001A
Serial Bus Type MICROWIRE
Endurance 1000000 Write/Erase Cycles
Data Retention Time-Min 200
Write Protection SOFTWARE
Alternate Memory Width 8
Dimensions
Height Seated (Max) 1.45mm
Length 2.95mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
