93AA46AT-I/MS
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 93AA46A Tape & Reel (TR) ic memory 2MHz 250ns 3mm 2mA
PDF
/
Buying Options
Total Price: USD $3.27
Unit Price: USD $3.26705
≥1 USD $3.26705
≥10 USD $2.6809
≥100 USD $2.5973
≥500 USD $2.5137
≥1000 USD $2.42915
Inventory: 1012
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 1.1mm
Technical
Write Protection SOFTWARE
Data Retention Time-Min 200
Write Cycle Time-Max (tWC) 6ms
Endurance 1000000 Write/Erase Cycles
Serial Bus Type MICROWIRE
Standby Current-Max 0.000001A
Density 1 kb
Write Cycle Time - Word, Page 6ms
Memory Width 8
Memory Interface SPI
Memory Format EEPROM
Access Time 250 ns
Clock Frequency 2MHz
Memory Type Non-Volatile
Nominal Supply Current 2mA
Memory Size 1Kb 128 x 8
Interface Serial
Power Supplies 2/5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 8
Base Part Number 93AA46A
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 2.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 1.8V~5.5V
Technology CMOS
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2003
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 7 Weeks
